Copper Pipe WEIGHT, DIMENSIONS CHART in mm, kg PDF Online

Copper Tube and Pipe WEIGHT, DIMENSIONS CHART in mm, kg, 15mm copper pipe weight

C-Fit Copper is a highly acclaimed Copper Pipe Fittings Manufacturer in India. The following tables show standard sizes of Copper Tubes of three types (types K, type L, and type M) or (type X, Y and Z), standard wall thickness, and standard accurate weight per unit length of the tube. Generally each length of tube is 3 metres or 10 feet in length or 5.8 metres and 20 feet in length.

All copper tube and copper tube fittings dimensions are in accordance with ASTM B88, ASTM B16.22, BS EN 13348, ASTM B280 and BS EN 1254, BS EN 1057. The Copper tube wall thickness and tolerance are specified in millimeters. The mass of the tube per unit length is given in kilograms per metre(kg/m) as per standard specifications all around the world. The Pipe’s Outer diameter(OD), Thickness of the Pipe (T) is considered the measurement in each of the Copper Pipe Diameter chart and copper pipe gauge chart below.

Copper Tube for Air Conditioning and Refrigeration (ACR) – Dimensions and Working Pressures as per ASTM B280 Standard

Nominal Size (inches)	Annealed (A) or Drawn Temper (D)	Outside Diameter (inches)	Inside Diameter (inches)	Wall Thickness (inches)	Cross Sectional Area of Bore (square inches)
1/8	A	0.125 3.18	0.065 1.65	0.030 0.762	0.0033 2.13
3/16	A	0.187 4.75	0.128 3.25	0.030 0.762	0.0129 8.32
1/4	A	0.250 6.35	0.190 4.83	0.030 0.762	0.0284 18.3
5/16	A	0.312 7.92	0.248 6.3	0.032 0.813	0.0483 31.2
3/8	A	0.375 9.52	0.311 7.9	0.032 0.813	0.076 49
	D	0.375 9.52	0.315 8	0.030 0.762	0.078 50.3
1/2	A	0.500 12.7	0.436 11.1	0.032 0.813	0.149 96.1
	D	0.500 12.7	0.430 10.9	0.035 0.889	0.145 93.5
5/8	A	0.625 15.9	0.555 14.1	0.035 0.889	0.242 156
	D	0.625 15.9	0.545 13.8	0.040 1.02	0.233 150
3/4	A	0.750 19	0.680 17.3	0.035 0.889	0.363 234
	A	0.750 19	0.666 16.9	0.042 1.07	0.348 225
	D	0.750 19	0.666 16.9	0.042 1.07	0.348 225
7/8	A	0.875 22.2	0.785 19.9	0.045 1.14	0.484 312
	D	0.875 22.2	0.785 19.9	0.045 1.14	0.484 312
1 1/8	A	1.125 28.6	1.025 26	0.050 1.27	0.825 532
	D	1.125 28.6	1.025 26	0.050 1.27	0.825 532
1 3/8	A	1.375 34.9	1.265 32.1	0.055 1.4	1.26 813
	D	1.375 34.9	1.265 32.1	0.055 1.4	1.26 813

BS 2871 Copper Tubes Table X, Y and Z – Working Pressures vs. BS 2871 Copper Tubes Table X, Y and Z – Working Size

The following copper pipe weight chart pdf shows the Pipe sizes, dimensions and working pressure of the Coppers Pipes as per the International Standards. The below copper pipe size chart pdf is in accordance with BS 2871 Copper Tube Table X, Table Y and Table Z respectively.

Nom. Diameter (mm)	Outside Diameter (mm)	Table X Half hard light gauge tube		Table Y Half hard an annealed tube		Table Z Hard drawn thin wall tube
		Thickness (mm)	Maximum Working Pressure (N/mm2)	Thickness (mm)	Maximum Working Pressure (N/mm2)	Thickness (mm)	Maximum Working Pressure (N/mm2)
6	6 0.236	0.6 0.0236	13.3 1929	0.8 0.0315	14.4 2088	0.5 0.0197	11.3 1639
8	8 0.315	0.6 0.0236	9.7 1407	0.8 0.0315	10.5 1523	0.5 0.0197	9.8 1421
10	10 0.394	0.6 0.0236	7.7 1117	0.8 0.0315	8.2 1189	0.5 0.0197	7.8 1131
12	12 0.472	0.6 0.0236	6.3 914	0.8 0.0315	6.7 972	0.5 0.0197	6.4 928
15	15 0.591	0.7 0.0276	5.8 841	1 0.0394	6.7 972	0.5 0.0197	5 725
18	18 0.709	0.8 0.0315	5.6 812	1 0.0394	5.5 798	0.6 0.0236	5 725
22	22 0.866	0.9 0.0354	5.1 740	1.2 0.0472	5.7 827	0.6 0.0236	4.1 595
28	28 1.1	0.9 0.0354	4 580	1.2 0.0472	4.2 609	0.6 0.0236	3.2 464
35	35 1.38	1.2 0.0472	4.2 609	1.5 0.0591	4.1 595	0.7 0.0276	3 435
42	42 1.65	1.2 0.0472	3.5 508	1.5 0.0591	3.4 493	0.8 0.0315	2.8 406
54	54 2.13	1.2 0.0472	2.7 392	2 0.0787	3.6 522	0.9 0.0354	2.5 363
67	67 2.64	1.2 0.0472	2 290	2 0.0787	2.8 406	1 0.0394	2 290
76.1	76.2 3	1.5 0.0591	2.4 348	2 0.0787	2.5 363	1.2 0.0472	1.9 276
108	108.1 4.26	1.5 0.0591	1.7 247	2.5 0.0984	2.2 319	1.2 0.0472	1.7 247
133	133.4 5.25	1.5 0.0591	1.4 203			1.5 0.0591	1.6 232
159	159.4 6.28	2 0.0787	1.5 218			1.5 0.0591	1.5 218

ASTM B88 Copper Pipe and Tubes Dimensions – Type K, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type K

Here, you can find below the  weight of copper pipe as per Copper Pipes and Tubes – Copper Types Chart of Type K standard specifications:

Type K Copper Pipes and Tubes are characterized by thick walls and have high durability hence suitable to be used underground and high pressure. C-Fit Copper offers high-quality Type K pipes, and high durability, and corrosion-resistance are guaranteed.

Nominal Size (inches)	Actual Outside Diameter (inches)		Tolerance on Outside Diameter (inches)		Wall Thickness (inches)		Weight (lb/ft)
			Annealed(1)	Drawn(2)	Nominal	Tolerance
1/4	3/8	0.375 9.52	0.002 0.0508	0.001 0.0254	0.035 0.889	0.0035 0.0889	0.133
3/8	1/2	0.500 12.7	0.0025 0.0635	0.001 0.0254	0.049 1.24	0.005 0.127	0.269
1/2	5/8	0.625 15.9	0.0025 0.0635	0.001 0.0254	0.049 1.24	0.005 0.127	0.344
5/8	3/4	0.750 19	0.0025 0.0635	0.001 0.0254	0.049 1.24	0.005 0.127	0.418
3/4	7/8	0.875 22.2	0.003 0.0762	0.001 0.0254	0.065 1.65	0.006 0.152	0.641
1	1 1/8	1.125 28.6	0.0035 0.0889	0.0015 0.0381	0.065 1.65	0.006 0.152	0.837
1 1/4	1 3/8	1.375 34.9	0.004 0.102	0.0015 0.0381	0.065 1.65	0.006 0.152	1.04
1 1/2	1 5/8	1.625 41.3	0.0045 0.114	0.002 0.0508	0.072 1.83	0.007 0.178	1.36
2	2 1/8	2.125 54	0.005 0.127	0.002 0.0508	0.083 2.11	0.008 0.203	2.06
2 1/2	2 5/8	2.625 66.7	0.005 0.127	0.002 0.0508	0.095 2.41	0.010 0.254	2.92
3	3 1/8	3.125 79.4	0.005 0.127	0.002 0.0508	0.109 2.77	0.011 0.279	4.00
3 1/2	3 5/8	3.625 92.1	0.005 0.127	0.002 0.0508	0.120 3.05	0.012 0.305	5.12
4	4 1/8	4.125 105	0.005 0.127	0.002 0.0508	0.134 3.4	0.013 0.33	6.51
5	5 1/8	5.125 130	0.005 0.127	0.002 0.0508	0.160 4.06	0.016 0.406	9.67
6	6 1/8	6.125 156	0.005 0.127	0.002 0.0508	0.192 4.88	0.019 0.483	13.87

ASTM B88 Copper Pipe and Tubes Dimensions – Type L, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type L

Here, you can find below the weight of copper pipe as per Copper Pipes and Tubes – Copper Types Chart of Type L standard specifications:

Nominal Size (inches)	Actual Outside Diameter (inches)		Tolerance on Outside Diameter (inches)		Wall Thickness (inches)		Weight (lb/ft)
			Annealed	Drawn	Nominal	Tolerance
1/4	3/8	0.375 9.52	0.002 0.0508	0.001 0.0254	0.030 0.762	0.003 0.0762	0.126
3/8	1/2	0.500 12.7	0.0025 0.0635	0.001 0.0254	0.035 0.889	0.004 0.102	0.198
1/2	5/8	0.625 15.9	0.0025 0.0635	0.001 0.0254	0.040 1.02	0.004 0.102	0.285
5/8	3/4	0.750 19	0.0025 0.0635	0.001 0.0254	0.042 1.07	0.004 0.102	0.362
3/4	7/8	0.875 22.2	0.003 0.0762	0.001 0.0254	0.045 1.14	0.004 0.102	0.455
1	1 1/8	1.125 28.6	0.0035 0.0889	0.0015 0.0381	0.050 1.27	0.005 0.127	0.655
1 1/4	1 3/8	1.375 34.9	0.004 0.102	0.0015 0.0381	0.055 1.4	0.006 0.152	0.884
1 1/2	1 5/8	1.625 41.3	0.0045 0.114	0.002 0.0508	0.060 1.52	0.006 0.152	1.14
2	2 1/8	2.125 54	0.005 0.127	0.002 0.0508	0.070 1.78	0.007 0.178	1.75
2 1/2	2 5/8	2.625 66.7	0.005 0.127	0.002 0.0508	0.080 2.03	0.008 0.203	2.48
3	3 1/8	3.125 79.4	0.005 0.127	0.002 0.0508	0.090 2.29	0.009 0.229	3.33
3 1/2	3 5/8	3.625 92.1	0.005 0.127	0.002 0.0508	0.100 2.54	0.010 0.254	4.29
4	4 1/8	4.125 105	0.005 0.127	0.002 0.0508	0.114 2.9	0.011 0.279	5.38
5	5 1/8	5.125 130	0.005 0.127	0.002 0.0508	0.125 3.18	0.012 0.305	7.61
6	6 1/8	6.125 156	0.005 0.127	0.002 0.0508	0.140 3.56	0.014 0.356	10.20

ASTM B88 Copper Pipe and Tubes Dimensions – Type M, ASTM B88 – Seamless Copper Water Tubes – Dimensions – Type M

Here, you can find below the weight of ASTM B88 copper pipe as per Copper Pipes and Tubes – Copper Types Chart of Type M standard specifications:

Nominal Size (inches)	Actual Outside Diameter (inches)		Tolerance on Outside Diameter (inches)		Wall Thickness (inches)		Weight (lb/ft)
			Annealed	Drawn	Nominal	Tolerance
1/4	3/8	0.375 9.52	0.002 0.0508	0.001 0.0254	–	–	0.106
3/8	1/2	0.500 12.7	0.0025 0.0635	0.001 0.0254	0.025 0.635	0.002 0.0508	0.144
1/2	5/8	0.625 15.9	0.0025 0.0635	0.001 0.0254	0.028 0.711	0.003 0.0762	0.203
5/8	3/4	0.750 19	0.0025 0.0635	0.001 0.0254	–	–	0.263
3/4	7/8	0.875 22.2	0.003 0.0762	0.001 0.0254	0.032 0.813	0.003 0.0762	0.328
1	1 1/8	1.125 28.6	0.0035 0.0889	0.0015 0.0381	0.035 0.889	0.004 0.102	0.464
1 1/4	1 3/8	1.375 34.9	0.004 0.102	0.0015 0.0381	0.042 1.07	0.004 0.102	0.681
1 1/2	1 5/8	1.625 41.3	0.0045 0.114	0.002 0.0508	0.049 1.24	0.005 0.127	0.94
2	2 1/8	2.125 54	0.005 0.127	0.002 0.0508	0.058 1.47	0.006 0.152	1.46
2 1/2	2 5/8	2.625 66.7	0.005 0.127	0.002 0.0508	0.065 1.65	0.006 0.152	2.03
3	3 1/8	3.125 79.4	0.005 0.127	0.002 0.0508	0.072 1.83	0.007 0.178	2.68
3 1/2	3 5/8	3.625 92.1	0.005 0.127	0.002 0.0508	0.083 2.11	0.008 0.203	3.58
4	4 1/8	4.125 105	0.005 0.127	0.002 0.0508	0.095 2.41	0.010 0.254	4.66
5	5 1/8	5.125 130	0.005 0.127	0.002 0.0508	0.109 2.77	0.011 0.279	6.66
6	6 1/8	6.125 156	0.005 0.127	0.002 0.0508	0.122 3.1	0.012 0.305	8.91

BS EN 13348 Medical Grade Pipe (Typically available dimensions in ready)

BS EN 13348 Medical Grade Pipe copper fitting dimensions.

The below dimensional chart describes the specified copper pipe sizes in mm to be used in conformance with BS EN 13348 Medical Grade (Degreased and Carbon Free).

Nominal Outside Diameter (mm)	Tube Length (m)	Wall Thickness (mm)
12	6	0.6
15	3, 6	0.7
22	3, 6	0.9
28	3, 6	0.9
35	6	1.0
42	6	1.0
54	6	1.0
67	6	1.5
76	6	1.5
108	6	1.5
133	6	1.5
159	6	2.0
219	6	3.0

BS EN 13348 Medical Grade Pipe (Typical Temper of Material Required as per Standard)​

You can find the below Mechanical Composition and Temper of BS EN 13348 Copper Pipes and Tube here. The mechanical composition of copper fittings are the same as shown in the below chart. You can also view the same by checking the “copper fitting dimensions chart” on this page.

Material Temper		Tensile Strength	Elongation min.	Vickers Hardness
Designation	Commonly used term	(MPa)	(%)	HV5
R250	half hard	250	30, 20	75 – 100
R290	hard	290	3	over 100

ASTM B819 Seamless Copper Tubes for Medical Gas Systems – Dimensions Type K

Nominal Size	Outside Diameter (in)	Inside Diameter (in)	Wall Thickness (in)	Internal Volume of Tube (ft3/ft)
1/4	0.375	0.305	0.035	0.00051
3/8	0.500	0.402	0.049	0.00088
1/2	0.625	0.527	0.049	0.00151
5/8	0.750	0.652	0.049	0.00232
3/4	0.875	0.745	0.065	0.00303
1	1.125	0.995	0.065	0.00540
1 1/4	1.375	1.245	0.065	0.00845
1 1/2	1.625	1.481	0.072	0.0120
2	2.125	1.959	0.083	0.0209
2 1/2	2.625	2.435	0.095	0.0323
3	3.125	2.907	0.109	0.0461
4	4.125	3.857	0.134	0.0811
5	5.125	4.805	0.160	0.126
6	6.125	5.741	0.192	0.180
8	8.125	7.583	0.271	0.314

ASTM B819 Seamless Copper Tubes for Medical Gas Systems – Dimensions – Type L

Nominal Size	Outside Diameter (in)	Inside Diameter (in)	Wall Thickness (in)	Internal Volume of Tube (ft3/ft)
1/4	0.375	0.315	0.030	0.00054
3/8	0.500	0.430	0.035	0.00101
1/2	0.625	0.545	0.040	0.00162
5/8	0.750	0.666	0.042	0.00242
3/4	0.875	0.785	0.045	0.00336
1	1.125	1.025	0.050	0.00573
1 1/4	1.375	1.265	0.055	0.00873
1 1/2	1.625	1.505	0.060	0.0124
2	2.125	1.985	0.070	0.0215
2 1/2	2.625	2.465	0.080	0.0331
3	3.125	2.945	0.090	0.0473
4	4.125	3.905	0.110	0.0832
5	5.125	4.875	0.125	0.130
6	6.125	5.854	0.140	0.186
8	8.125	7.725	0.200	0.325

Copper Tube for Air Conditioning and Refrigeration (ACR) Working Pressures as per ASTM B280 Standard specs

ACR copper tubes are created to withstand high working pressures as detailed in the ASTM b280 standard. These tubes are reliable enough in their work and safe in HVAC systems that serve different temperature and pressure conditions.

Nominal Size (inches)	Max. Working Pressure (psi)
	Annealed Coils	Annealed Straight Lengths	Drawn Straight Lengths
1/8	2613	–	–
3/16	1645	–	–
1/4	1195	–	–
5/19	1017	–	–
3/8	836	777	1524
1/2	618	664	1302
5/8	525	615	1206
3/4	435	538	1055
7/8	495	496	972
1 1/8	420	421	825
1 3/8	373	374	733
1 5/8	347	348	682
2 1/8	–	309	607
2 5/8	–	286	560
3 1/8	–	270	529
3 5/8	–	258	506
4 1/8	–	249	489

ASTM B88M – Seamless Copper Water Tubes – Metric Dimensions – Type A

ASTM B88M Type A seamless copper water tubes are available to metric size and are utilized in high pressure water distribution systems. They have good corrosion resistance, durability and reliability in residential, commercial and industrial plumbing purposes.

Nominal Size Outside Diameter (mm)	Wall Thickness (mm)	Tolerance +/- Maximum Deviation at any Point (mm)	Weight (kg/m)
6 0.236	0.9 0.0354	0.08 0.00315	0.12
8 0.315	0.9 0.0354	0.09 0.00354	0.18
10 0.394	0.9 0.0354	0.09 0.00354	0.23
12 0.472	1.2 0.0472	0.1 0.00394	0.36
15 0.591	1.2 0.0472	0.1 0.00394	0.47
18 0.709	1.2 0.0472	0.1 0.00394	0.57
22 0.866	1.6 0.063	0.15 0.00591	0.92
28 1.1	1.6 0.063	0.15 0.00591	1.19
35 1.38	1.6 0.063	0.15 0.00591	1.50
42 1.65	1.8 0.0709	0.2 0.00787	2.03
54 2.13	2.1 0.0827	0.2 0.00787	3.06
67 2.64	2.4 0.0945	0.25 0.00984	4.35
79 3.11	2.8 0.11	0.3 0.0118	5.99
105 4.13	3.4 0.134	0.35 0.0138	9.70
130 5.12	4.0 0.157	0.4 0.0157	14.2
156 6.14	4.8 0.189	0.5 0.0197	20.3
206 8.11	6.8 0.268	0.7 0.0276	38.0
257 10.1	8.5 0.335	0.85 0.0335	59.3
308 12.1	10.3 0.406	1 0.0394	86.1

ASTM B88M – Seamless Copper Water Tubes – Metric Dimensions – Type B

Nominal Size Outside Diameter (mm)	Wall Thickness (mm)	Tolerance +/- Maximum Deviation at any Point (mm)	Weight (kg/m)
6 0.236	0.7 0.0276	0.07 0.00276	0.10
8 0.315	0.8 0.0315	0.08 0.00315	0.16
10 0.394	0.8 0.0315	0.08 0.00315	0.21
12 0.472	0.9 0.0354	0.09 0.00354	0.28
15 0.591	1.0 0.0394	0.1 0.00394	0.39
18 0.709	1.0 0.0394	0.1 0.00394	0.48
22 0.866	1.1 0.0433	0.1 0.00394	0.65
28 1.1	1.2 0.0472	0.1 0.00394	0.90
35 1.38	1.4 0.0551	0.15 0.00591	1.32
42 1.65	1.5 0.0591	0.15 0.00591	1.71
54 2.13	1.7 0.0669	0.15 0.00591	2.50
67 2.64	2.0 0.0787	0.15 0.00591	3.65
79 3.11	2.3 0.0906	0.2 0.00787	4.95
105 4.13	2.8 0.11	0.25 0.00984	8.04
130 5.12	3.1 0.122	0.3 0.0118	11.0
156 6.14	3.5 0.138	0.3 0.0118	15.0
206 8.11	5.0 0.197	0.35 0.0138	28.2
257 10.1	6.3 0.248	0.5 0.0197	44.4
308 12.1	7.1 0.28	0.65 0.0256	60.0

ASTM B88M – Seamless Copper Water Tubes – Metric Dimensions – Type C

Nominal Size Outside Diameter (mm)	Wall Thickness (mm)	Tolerance +/- Maximum Deviation at any Point (mm)	Weight (kg/m)
6 0.236	0.6 0.0236	–	0.09
8 0.315	0.6 0.0236	–	0.13
10 0.394	0.6 0.0236	–	0.16
12 0.472	0.6 0.0236	0.06 0.00236	0.19
15 0.591	0.7 0.0276	0.07 0.00276	0.28
18 0.709	0.7 0.0276	0.07 0.00276	0.34
22 0.866	0.8 0.0315	0.08 0.00315	0.48
28 1.1	0.9 0.0354	0.09 0.00354	0.69
35 1.38	1.1 0.0433	0.1 0.00394	1.05
42 1.65	1.2 0.0472	0.1 0.00394	1.37
54 2.13	1.5 0.0591	0.15 0.00591	2.21
67 2.64	1.6 0.063	0.15 0.00591	2.94
79 3.11	1.8 0.0709	0.2 0.00787	3.90
105 4.13	2.4 0.0945	0.25 0.00984	6.92
130 5.12	2.7 0.106	0.25 0.00984	9.65
156 6.14	3.1 0.122	0.3 0.0118	13.3
206 8.11	4.3 0.169	0.45 0.0177	24.4
257 10.1	5.4 0.213	0.55 0.0217	38.2
308 12.1	6.4 0.252	0.65 0.0256	54.2

Weight of All types of Copper Pipes and Tubes in inches and mm with the working pressure specified in kg and lbs:

• 12mm Copper Pipe Weight
• 15mm Copper Pipe Weight
• 22mm Copper Pipe Weight
• 42mm Copper Pipe Weight

• 1/4″ Copper Tube Weight (6mm Copper Coil Weight Information)
• 5/16″ Copper Tube Weight (8mm Copper Coil Weight Information)
• 3/8″ Copper Tube Weight (10mm Copper Coil Weight Information)
• 1/2″ Copper Tube Weight (12mm Copper Coil Weight Information)
• 5/8″ Copper Tube Weight (15mm Copper Coil Weight Information)
