Copper Flare Seal
Copper flare seals are small rings for plumbing and HVAC systems, which help make an air and water tight connection the pipe and flare fittings.
- Versatile Uses
- Leak-Free Connections
- Easy Maintenance
- Cost Savings
- Fewer Service Calls
- Lower Operating Costs
- Eco-Friendly
- Enhanced Integrity
- Fields of Use :
- HAVC Min-Splits
- LP Gas Lines
- Filter Driers
- Oil Filters
- Pilot Lines
- Evaporator Pressure Regulators
- Hi-Low Pressure Controls
- Thermostatic Expansion Valves
Copper Flare Seal Manufacturer and Exporter
Presenting the revolutionary invention, the copper flare seal and how this provides the optimal flare connection on instruments. By getting the best of non-permanent serviceable components and a watertight seal, this cutting edge item proves ideal for HVAC/R specialists. It also has the potential to fix any little existing leaks that may be present at the office facility.
Table of Contents
How to use copper flare seal
- Prepare the Fitting: Make sure the male flare fitting is clean and there is no dirt or sand getting in between the female and male flare fitting.
- Position the Seal: Insert the flare seat into the fitting leaving the flare seal resting on the surface of this flare seat, but to do that firmly.
- Secure the Connection: To secure it into place with little possibility of a leak, tighten to the torque settings required.
Flare Seal Mini-Split System Price List and Table
- $14
- $15
- $16
- $16
Flare Seal Single System Price List and Table
- $28
- $30
- $33
- $38
- $42
- $95
Principal benefits of Copper Flaretite Seal
- Leak-Free Connections: Provides confidence in every flare connection taking out leakage issues that may arise.
- Cost Savings: Helps to cut the annual refrigerant loss hence resulting to amount to several benefits such as saving on costs.
- Lower Operating Costs: Without leak, system operational cost is low, system efficiency is high .
- OEM Advantage: Makes them more competitive than their counterparts who are not using this solution.
- Versatile Use: Ensures non-weeping in newly-designed or re-designed vertical or horizontal system for higher reliability.
- Easy Maintenance: In some ways it aids on the installation and maintenance hence making repairs easier.
- Fewer Service Calls: Helps also minimize the emission of refrigerant gas, fewer service calls thus, less time and money wasted.
- Eco-Friendly: This reduces emissions of refrigerants into the atmosphere and thus it supports the environment sustainable.
- Enhanced Integrity: Fortifies every flaretite connection thereby enhancing the general endurance of the system.
Flaretite Seal Dimensions, Size Chart and Tables
Flaretite seals are important items which are employed in several sectors to achieve tight sealing of flare fittings. Candidate to these aspects, these seals have been conceived with an increased sealing ability, which make them very appropriate for applications where strong, and long-lasting connections are required. The following aspects should be kept in mind while choosing the right seal for one’s specific requirements as far as Flaretite seals are concerned: the dimensions; size charts; and size tables.
JIC 37° Flare (SAE J514) Flaretite Seal Dimensions, Size Chart and Table
| Inch size | Dash size | I.D. (B) inches | O.D. (A) inches |
|---|---|---|---|
| 1⁄8 | -2 | 1⁄8 | 0.27 |
| 3⁄16 | -3 | 3⁄16 | 0.34 |
| 1⁄4 | -4 | 1⁄4 | 0.39 |
| 5⁄16 | -5 | 5⁄16 | 0.45 |
| 3⁄8 | -6 | 3⁄8 | 0.51 |
| 1⁄2 | -8 | 1⁄2 | 0.69 |
| 5⁄8 | -10 | 5⁄8 | 0.81 |
| 3⁄4 | -12 | 3⁄4 | 0.98 |
| 7⁄8 | -14 | 7⁄8 | 1.1 |
| 1 | -16 | 1 | 1.23 |
| 1 1⁄4 | -20 | 1 1⁄4 | 1.54 |
| 1 1⁄2 | -24 | 1 1⁄2 | 1.79 |
| 2 | -32 | 2 | 2.42 |
SAE 45° Flare (SAE J512) Flaretite Seal Dimensions, Size Chart and Table
| Inch size | Dash size | I.D. (B) inches | O.D. (A) inches |
|---|---|---|---|
| 1⁄8 | -2 | 1⁄8 | 0.27 |
| 3⁄16 | -3 | 3⁄16 | 0.34 |
| 1⁄4 | -4 | 1⁄4 | 0.39 |
| 5⁄16 | -5 | 5⁄16 | 0.45 |
| 3⁄8 | -6 | 3⁄8 | 0.57 |
| 1⁄2 | -8 | 1⁄2 | 0.69 |
| 5⁄8 | -10 | 5⁄8 | 0.81 |
| 3⁄4 | -12 | 3⁄4 | 0.99 |
| 7⁄8 | -14 | 7⁄8 | 1.16 |
| 1 | -16 | 1 | 1.29 |
30° Flare JIS 300 Flaretite Seal Dimensions, Size Chart and Table
| Inch size | Dash size | I.D. (B) inches | O.D. (A) inches |
|---|---|---|---|
| 1⁄8 | -2 | 1⁄8 | 0.35 |
| 1⁄4 | -4 | 1⁄4 | 0.47 |
| 3⁄8 | -6 | 3⁄8 | 0.6 |
| 1⁄2 | -8 | 1⁄2 | 0.75 |
| 5⁄8 | -10 | 5⁄8 | 0.8 |
| 3⁄4 | -12 | 3⁄4 | 0.97 |
| 1 | -16 | 1 | 1.22 |
| 1 1⁄4 | -20 | 1 1⁄4 | 1.56 |
| 1 1⁄2 | -24 | 1 1⁄2 | 1.79 |
| 2 | -32 | 2 | 2.26 |
C-Fit Copper is a leading Exporter of Copper Flare Seals
Copper Flare Seals is one of the major products that C-Fit Copper proudly offers as an exporter for gases and equipment, which are characterized by precision, durability and performance. Copper Flare Seals available with us are designed for making leak free connection in refrigeration, HVAC and gas line system for residential as well as industrial use. These flare seals are made of premium copper to give maximum protection against corrosion, high heat and pressure. They come in the standard sizes and manufactured to international quality, and our customers are global. C-Fit Copper being a leading exporter ensures quality and satisfaction of the customer that’s why Copper Flare Seal purchased from Kanchan sales is preferred all over the world.
